Rear heated seats circuit, without rear a/c for BMW X6 E71 (2007-2012)
Rear heated seats circuit, without rear a/c
BLK WIRE
BLU WIRE
BRN WIRE
FUSE
GRN WIRE
GRN/VIO WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 RELAY ENERGIZED
LEFT REAR SEAT BACKREST HEATING
LEFT REAR SEAT CUSHION HEATING
LEFT REAR SEAT HEATING SWITCH
POWER DISTRIBUTION SYSTEM
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/YEL WIRE
RIGHT REAR SEAT BACKREST HEATING
RIGHT REAR SEAT CUSHION HEATING
RIGHT REAR SEAT HEATING SWITCH
TERMINAL 15 POWER SAVING RELAY
VIO WIRE
WHT WIRE
YEL WIRE
