Front heated seats circuit, with memory for BMW X6 E71 (2007-2012)
Front heated seats circuit, with memory
BLK/BRN WIRE
BLK/VIO WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT BACKREST HEATING
DRIVER'S SEAT CUSHION HEATING
DRIVER'S SEAT MODULE
FUSE
GRN WIRE
HEATING/ AIR CONDITIONING SYSTEM
HOT W/
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
JUNCTION BOX ELECTRONICS
ORG/GRN WIRE
PASSENGER'S SEAT BACKREST HEATING
PASSENGER'S SEAT CUSHION HEATING
PASSENGER'S SEAT MODULE
REAR POWER DISTRIBUTION BOX
RED/BRN WIRE
RED/GRN WIRE
RELAY ENERGIZED
W/ MULTI- FUNCTION SEATS
W/O MULTI- FUNCTION SEATS
WHT/BLU WIRE
