Parking assistant circuit for BMW X6 E71 (2007-2012)
Parking assistant circuit
BRN/BLK WIRE
BRN/BLU WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FUSE
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRN/WHT WIRE
HOT W/ TERMINAL 15 RELAY ENERGIZED
LEFT FRONT CENTER ULTRASONIC SENSOR (FRONT BUMPER COVER)
LEFT FRONT ULTRASONIC SENSOR (FRONT BUMPER COVER)
LEFT REAR CENTER ULTRASONIC SENSOR (REAR BUMPER COVER)
LEFT REAR ULTRASONIC SENSOR (REAR BUMPER COVER)
ORG/GRN WIRE
PARK DISTANCE CONTROL (PDC) (RIGHT REAR QUARTER PANEL)
REAR POWER DISTRIBUTION BOX (RIGHT REAR QUARTER PANEL)
RIGHT FRONT CENTER ULTRASONIC SENSOR (FRONT BUMPER COVER)
RIGHT FRONT ULTRASONIC SENSOR (FRONT BUMPER COVER)
RIGHT REAR CENTER ULTRASONIC SENSOR (REAR BUMPER COVER)
RIGHT REAR ULTRASONIC SENSOR (REAR BUMPER COVER)
WHT WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
