Power mirrors circuit, with lin bus function for BMW X6 E71 (2007-2012)
Power mirrors circuit, with lin bus function
45 46 23 22 CAN L CAN H
BRN WIRE
CAMERA
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SWITCH BLOCK
DRIVER'S SIDE OUTSIDE MIRROR
FOOTWELL MODULE
GRN WIRE
GRY/RED WIRE
NAVIGATION SYSTEM
NCA WIRE
ORG/GRN WIRE
PASSENGER'S SIDE OUTSIDE MIRROR
RED WIRE
RED/GRY WIRE
RELAY ENERGIZED JUNCTION BOX (UNDER RIGHT SIDE OF DASH) FUSE
WHT WIRE
WHT/BRN WIRE
YEL WIRE
