Electronic power steering circuit, without al active steering for BMW X6 E71 (2007-2012)
Electronic power steering circuit, without al active steering
ACTIVE STEERING (UNDER REAR OF LEFT FRONT FENDER)
BLK WIRE
BLK/BRN WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ECO VALVE
ELECTRIC LOCK
ELECTRONICS JUNCTION BOX
FUSE
GRN/RED WIRE
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
NCA WIRE
RED WIRE
RED/BRN WIRE
RELAY ENERGIZED
STEERING GEAR
W/ ACTIVE FRONT STEERING
W/O ACTIVE FRONT STEERING
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BRN WIRE
