BMW X6 E71 (2007-2012) w/o lights package Wiring diagram

BLK/BLU WIRE BLK/WHT WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR ENTRANCE LIGHT DRIVER'S DOOR EXIT LIGHT EARLY PRODUCTION LATE PRODUCTION 1 2 FOOTWELL MODULE FUSE GRN WIRE GRY/GRN WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ INTERIOR LIGHT) LEFT FRONT FOOTWELL LIGHT LEFT FRONT MAKE- UP MIRROR LIGHT LEFT LUGGAGE COMPARTMENT LIGHT LEFT REAR DOOR COURTESY LIGHTING LEFT REAR DOOR EXIT LIGHT LEFT REAR FOOTWELL LIGHT LEFT REAR INTERIOR LIGHT MAP READING LIGHT MAP READING LIGHT ON NOISE SUPPRESSOR FILTER OFF OFF ON ORG/GRN WIRE PASSENGER'S DOOR ENTRANCE LIGHT PASSENGER'S DOOR EXIT LIGHT POWER DISTRIBUTION SYSTEM REAR COMPARTMENT INTERIOR LIGHT (W/ LIGHTS PACKAGE) 33 34 10 11 REAR POWER DISTRIBUTION BOX (RIGHT REAR QUARTER PANEL) RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT FOOTWELL LIGHT RIGHT FRONT MAKE- UP MIRROR LIGHT RIGHT LUGGAGE COMPARTMENT LIGHT RIGHT REAR DOOR COURTESY LIGHTING RIGHT REAR DOOR EXIT LIGHT RIGHT REAR FOOTWELL LIGHT ROOF FUNCTION CONTROL CENTER TOP LIGHT TRUNK LID CENTRAL LOCKING DRIVE VIO/BRN WIRE W/ LIGHTS PACKAGE W/O LIGHTS PACKAGE WHT/BRN WIRE
