BMW X6 E71 (2007-2012) servotronic blower output stage Wiring diagram
This page shows the only wiring diagram for the component.servotronic blower output stage, which is found in the car BMW X6 E71 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram servotronic blower output stage (1 of 1)
AIR SUSPENSION COMPRESSOR RELAY
ALTERNATOR
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
DME RELAY
DYNAMIC STABILITY CONTROL
ELECTRIC FAN CUT-OUT RELAY (W/ TRAILER MODULE)
FAN FARE HORN RELAY
FOOTWELL MODULE
FROM FUSE
FUSE
FUSE BOX
FUSE FUSE
GRN WIRE
HEADLIGHT WASHER RELAY
HEATED REAR WINDOW RELAY
INTELLIGENT BATTERY SENSOR
JUMP
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LUGGAGE WELL B+ TERMINAL POINT
NCA WIRE
PARKING BRAKE PUSH BUTTON
REAR WINDOW WIPER RELAY
RED WIRE
ROOF FUNCTION CONTROL CENTER
SECONDARY AIR PUMP RELAY
SERVOTRONIC BLOWER OUTPUT STAGE
SIREN, DIGITAL MOTOR ELECTRONICS TILT ALARM SENSOR (DME) CONTROL UNIT
STARTER
TERMINAL 15 POWER SAVING RELAY
TERMINAL POINT
TO CAR ACCESS SYSTEM (DIAGRAM 5 OF 5)
TO ELECTRONICS JUNCTION BOX (DIAGRAM 2 OF 5)
TO FUSE
TO REAR POWER DISTRIBUTION BOX (DIAGRAM 3 OF 5)
TO TERMINAL
VIO WIRE
WHT WIRE
WIPER RELAY
Go to component -> Power distribution circuit (1 of 5) -> SERVOTRONIC BLOWER OUTPUT STAGE
