BMW X6 E71 (2007-2012) left ventilation flap motor Wiring diagram
This page shows the only wiring diagram for the component.left ventilation flap motor, which is found in the car BMW X6 E71 (2007-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left ventilation flap motor (1 of 1)
1 2 3 4 5 6 7 8 9 10 STPPR GND L TEMP EXCHG LIN BUS
BACK PRESSURE FLAP MOTOR
BLU WIRE
BRN WIRE
DEFROSTER FLAP MOTOR
EVAPORATOR TEMPERATURE SENSOR
FRESH AIR/ RECIRCULATING AIR FLAP MOTOR
FUSE
FUSE FUSE
GND EVA TEMP SNS R TEMP EXCHG
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/RED WIRE
HEATING/AIR CONDITIONING SYSTEM
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE BOX
HOT W/
HOT W/ POWER SAVING TERMINAL 15 RELAY ENERGIZED FUSE CARRIER ENGINE ELECTRONICS
LEFT FOOTWELL FLAP MOTOR
LEFT FRONT STRATIFYING AIR FLAP MOTOR
LEFT HEATING HEAT EXCHANGER TEMPERATURE SENSOR
LEFT REAR FOOTWELL FLAP MOTOR
LEFT REAR STRATIFYING AIR FLAP MOTOR
LEFT VENTILATION FLAP MOTOR
ORG/ WIRE
RED WIRE
RED/BLU WIRE
RED/YEL WIRE
RELAY ENERGIZED REAR POWER DISTRIBUTION BOX (RIGHT REAR QUARTER PANEL)
RIGHT FOOTWELL FLAP MOTOR
RIGHT HEATING HEAT EXCHANGER TEMPERATURE SENSOR
RIGHT REAR FOOTWELL FLAP MOTOR
RIGHT VENTILATION FLAP MOTOR
STPPR PWR
YEL/BRN WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Automatic a/c circuit, with high a/c, with rear compartment blower (3 of 3) -> LEFT VENTILATION FLAP MOTOR
