Lane departure warning circuit, w/o camera for BMW X6 M F96 facelift (2023-2024)
Lane departure warning circuit, w/o camera
BLK/GRN WIRE
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER VEHICLE EXTERIOR MIRROR
DYNAMIC STABILITY CONTROL (DSC)/ VIRTUAL INTEGRATION PLATFORM (VIP)
FRONT PASSENGER VEHICLE EXTERIOR MIRROR
FUSE 215
FUSE 26
GRN WIRE
GRN/BLU WIRE
HOT AT ALL TIMES
HOT W/
LANE CHANGE WARNING LED
LEFT "C" PILLAR)
LEFT REAR SHORT RANGE RADAR SENSOR (HRSNL)
MEDIUM PLATFORM AUTOMATIC DRIVING FAN
MIRROR ELECTRONICS
ORG/GRN WIRE
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BLK WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT REAR SHORT RANGE RADAR SENSOR (HRSNR)
WHT/BLU WIRE
WHT/RED WIRE
