BMW X6 M F96 facelift (2023-2024) light source 18 wiring diagram
This page shows the only wiring diagram for the component.light source 18, which is found in the car BMW X6 M F96 facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
light source 18 wiring diagram (1 of 1)
BLU WIRE
BLU/WHT WIRE
BRN WIRE
CENTER CONSOLE LIGHTING
CENTER CONSOLE LIGHTING 2
CENTER DRIVER'S DOOR TRIM PANEL LIGHTING
CENTER DRIVER'S SIDE REAR DOOR TRIM PANEL LIGHTING
DRIVER'S DOOR INSIDE DOOR HANDLE LIGHT
DRIVER'S DOOR POCKET LIGHTING
DRIVER'S SIDE REAR DOOR POCKET LIGHTING
DRIVER'S SIDE REAR INSIDE DOOR HANDLE LIGHT
LEFT FRONT FOOTWELL LIGHT
LIGHT
LIGHT SOURCE 11
LIGHT SOURCE 12
LIGHT SOURCE 13
LIGHT SOURCE 14
LIGHT SOURCE 15
LIGHT SOURCE 16
LIGHT SOURCE 17
LIGHT SOURCE 18
LIGHT SOURCE 19
LIGHT SOURCE 20
LIGHT SOURCE 9
POWER DISTRIBUTION SYSTEM
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT FRONT FOOTWELL LIGHT
SOURCE 10
TOP DRIVER'S DOOR TRIM PANEL LIGHTING
TOP DRIVER'S SIDE REAR DOOR TRIM PANEL LIGHTING
YEL WIRE
YEL/GRY WIRE
Go to component -> Courtesy lamps circuit (5 of 7) -> LIGHT SOURCE 18
