BMW X6 M F96 facelift (2023-2024) interior lights button wiring diagram
This page shows the only wiring diagram for the component.interior lights button, which is found in the car BMW X6 M F96 facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
interior lights button wiring diagram (1 of 1)
AIR FRESHENER
AMBIENT LIGHT
BLK BRN/ WIRE
BLK WIRE
BRN BLK/ WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT CENTER ARMREST LIGHT
FUSE 250
FUSE 262
FUSE 36
FUSE 60
FUSE 61
FUSE 63
FUSE 64
FUSE 65
FUSE 66
FUSE 67
FUSE 68
GLOVE BOX LIGHT SWITCH
GLOVE COMPARTMENT LIGHT
GRY/BLU WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ TERMINAL
INSTRUMENT ILLUMINATION CIRCUIT
INTERIOR LIGHT)
INTERIOR LIGHTING
INTERIOR LIGHTS BUTTON
INTERIOR LIGHTS LOCATOR LIGHTING BUTTON
LEFT READING LAMP BUTTON
LEFT READING LAMP BUTTON LOCATOR LIGHTING
LEFT SIDE READING LIGHT
REAR INTERIOR LIGHT
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT FRONT VANITY MIRROR LIGHT
RIGHT FRONT VANITY MIRROR SWITCH
RIGHT READING LAMP BUTTON
RIGHT READING LAMP BUTTON LOCATOR LIGHTING
RIGHT READING LIGHT
ROOF FUNCTION CENTER
VIO WIRE
VIO/GRN WIRE
YEL WIRE
YEL/GRN WIRE
Go to component -> Courtesy lamps circuit (1 of 7) -> INTERIOR LIGHTS BUTTON
