BMW X6 M F96 facelift (2023-2024) front electric active roll stabilization wiring diagram
This page shows the only wiring diagram for the component.front electric active roll stabilization, which is found in the car BMW X6 M F96 facelift (2023-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
front electric active roll stabilization wiring diagram (1 of 1)
ALTERNATOR
AUXILIARY BATTERY
BATTERY
BATTERY ELECTRONICS
BLK WIRE
BRN WIRE
CAPACITOR BOX
COMPUTER DATA LINES SYSTEM
COOLANT PUMP RELAY
CRASH SAFETY MODULE
DYNAMIC STABILITY CONTROL (DSC)
ELECTRIC FAN CUT-OFF RELAY
ELECTROMECHANICAL POWER STEERING
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
FROM BODY DOMAIN CONTROLLER (DIAGRAM 2 OF 10)
FROM REAR POWER DISTRIBUTION BOX (DIAGRAM 5 OF 10)
FROM RIGHT FRONT POWER DISTRIBUTION BOX (DIAGRAM 3 OF 10)
FRONT ELECTRIC ACTIVE ROLL STABILIZATION
FRONT ELECTRIC AUXILIARY HEATER
FUSE 300
FUSE 400
FUSE 401
FUSE 402
FUSE 403
FUSE 404
FUSE 406
FUSE 408
FUSE 409
FUSE 508
FUSE BOX
FUSE BOX 2
GRN/BLK WIRE
GRY WIRE
GRY/GRN WIRE
GRY/YEL WIRE
INTELLIGENT BATTERY SENSOR
JUMP START TERMINAL
NCA WIRE
POWER CONTROL UNIT (W/O DUAL STORAGE SYSTEM)
REAR ELECTRIC ACTIVE ROLL STABILIZATION
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
SAFETY BATTERY TERMINAL GAS GENERATOR
STARTER MOTOR
SUPPLEMENTARY BATTERY FUSE BOX
TO FUSE 504 (DIAGRAM 2 OF 10)
TO INTEGRATED SUPPLY MODULE (DIAGRAM 8 OF 10)
TRANSFER TERMINAL POINT 2
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
Go to component -> Power distribution circuit (1 of 10) -> FRONT ELECTRIC ACTIVE ROLL STABILIZATION
