Charging circuit, w/ dual storage system for BMW X6 M F96 (2019-2023)
Charging circuit, w/ dual storage system
ALTERNATOR
AUXILIARY BATTERY
BATTERY
BATTERY ELECTRONICS
BLK WIRE
BRN WIRE
CAPACITOR BOX
COMPUTER DATA LINES SYSTEM
CRASH SAFETY MODULE
DIGITAL MOTOR ELECTRONICS
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
FUSE 244
FUSE 63
GRN/BLK WIRE
GRY WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/
INTELLIGENT BATTERY SENSOR
JUMP START TERMINAL
NCA WIRE
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BRN WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
SAFETY BATTERY TERMINAL GAS GENERATOR
STARTER MOTOR
TRANSFER TERMINAL POINT 2
VIO WIRE
WHT WIRE
