Seat ventilation circuit for BMW X6 M F96 (2019-2023)
Seat ventilation circuit (1 of 2)
AIR CONDITIONING
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SEAT MODULE
DRIVER'S SEAT BACKREST FAN 1
DRIVER'S SEAT BACKREST FAN 2
DRIVER'S SEAT BACKREST FAN 3
DRIVER'S SEAT BACKREST FAN 4
DRIVER'S SEAT CUSHION FAN 1
DRIVER'S SEAT CUSHION FAN 2
DRIVER'S SEAT CUSHION FAN 3
DRIVER'S SEAT CUSHION FAN 4
FUSE 53
FUSE 55
GRN WIRE
HOT W/
ORG/GRN WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
WHT/BRN WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Seat ventilation circuit (2 of 2)
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER SEAT MODULE
PASSENGER'S SEAT BACKREST FAN 1
PASSENGER'S SEAT BACKREST FAN 2
PASSENGER'S SEAT BACKREST FAN 3
PASSENGER'S SEAT BACKREST FAN 4
PASSENGER'S SEAT CUSHION FAN 1
PASSENGER'S SEAT CUSHION FAN 2
PASSENGER'S SEAT CUSHION FAN 3
PASSENGER'S SEAT CUSHION FAN 4
RED/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
