Access/start circuit for BMW X6 M F96 (2019-2023)
Access/start circuit (1 of 2)
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT CENTER CONSOLE INTERIOR ANTENNA
FUSE 244
FUSE 33
FUSE 4
FUSE 504
FUSE BOX
GRN/BLU WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRY/BLK WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
LEFT EXTERIOR ANTENNA
LUGGAGE COMPARTMENT ANTENNA
REAR CENTER CONSOLE INTERIOR ANTENNA
REAR POWER DISTRIBUTION BOX
RED WIRE
REMOTE CONTROL RECEIVER
RIGHT FRONT POWER DISTRIBUTION BOX
WHT/BLU WIRE
WHT/GRY WIRE
WHT/RED WIRE
Access/start circuit (2 of 2)
BLU/GRN WIRE
BODY DOMAIN CONTROLLER (RIGHT KICK PANEL)
BRN WIRE
BUMPER ANTENNA
CENTER CONSOLE CONTROL
COMPUTER DATA
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/RED WIRE
LINES SYSTEM
NFC NEAR-FIELD COMMUNICATION DRIVER OUTSIDE DOOR HANDLE ELECTRONICS
PASSENGER OUTSIDE DOOR HANDLE ELECTRONICS
REAR DRIVER'S SIDE OUTSIDE DOOR HANDLE ELECTRONICS
REAR PASSENGER'S SIDE OUTSIDE DOOR HANDLE ELECTRONICS
RED WIRE
RIGHT EXTERIOR ANTENNA
RING ANTENNA
START STOP BUTTON IND
START-STOP BUTTON
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
