Independent heating circuit for BMW X6 M F96 (2019-2023)
Independent heating circuit
AUTOMATIC A/C CIRCUIT
AUXILIARY HEATER COOLANT CHANGEOVER VALVE
AUXILIARY HEATER FUEL METERING PUMP
AUXILIARY HEATER RECIRCULATING PUMP
BLK WIRE
BLK/RED WIRE
BLK/YEL WIRE
BRN WIRE
FUSE 54
GRY WIRE
HOT W/
INDEPENDENT AUXILIARY HEATER
RED WIRE
RED/VIO WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
WHT/BRN WIRE
