BMW X6 M F96 (2019-2023) rear driver's side automatic soft close system drive wiring diagram
This page shows the only wiring diagram for the component.rear driver's side automatic soft close system drive, which is found in the car BMW X6 M F96 (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rear driver's side automatic soft close system drive wiring diagram (1 of 1)
CENTER PASSENGER'S SIDE REAR DOOR TRIM PANEL LIGHTING
FROM FUSE 214 (DIAGRAM 7 OF 10)
FRONT INTERIOR LIGHT
FUSE 254
FUSE 256
FUSE 257
FUSE 258
FUSE 267
INTERFERENCE SUPPRESSION FILTER 6
LEFT REVERSIBLE ELECTROMOTIVE ELECTRICALLY MOTORIZED REEL
LUGGAGE COMPARTMENT LAMP
PASSENGER'S SIDE REAR DOOR POCKET LIGHTING
PASSENGER'S SIDE REAR INSIDE DOOR HANDLE LIGHT
REAR DRIVER'S SIDE AUTOMATIC SOFT CLOSE SYSTEM DRIVE
REAR PASSENGER'S SIDE AUTOMATIC SOFT CLOSE SYSTEM DRIVE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RIGHT REAR SPEAKER LIGHTING
RIGHT REVERSIBLE ELECTROMOTIVE ELECTRICALLY MOTORIZED REEL
TAILGATE BUTTON ON INSIDE OF TRUNK LID
TOP PASSENGER REAR DOOR TRIM PANEL LIGHTING
TRAILER BRAKE SYSTEM PLUG CONNECTION
TRAILER MODULE
TRUNK COMPARTMENT LIGHT 2
TRUNK COMPARTMENT LIGHT TRUNK LID
TRUNK COMPARTMENT LIGHT TRUNK LID 2
TRUNK LID TAILGATE BUTTON
W/ TRAILER MODULE
W/O TRAILER MODULE
Go to component -> Power distribution circuit (9 of 10) -> REAR DRIVER'S SIDE AUTOMATIC SOFT CLOSE SYSTEM DRIVE
