BMW X6 M F96 (2019-2023) nca Wiring diagrams

This page contains all the electrical diagrams for the component. nca, in which he is found in the car BMW X6 M F96 (2019-2023). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

nca wiring diagram (21 of 78)

BLK WIRE COMPUTER DATA LINES SYSTEM FRONT ELECTRIC ACTIVE ROLL STABILIZATION FUSE 209 FUSE 408 FUSE 409 FUSE BOX 2 GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES HOT W/ NCA WIRE PNK WIRE PNK/BLK WIRE REAR ELECTRIC ACTIVE ROLL STABILIZATION REAR POWER DISTRIBUTION BOX RED WIRE RED/GRN WIRE RELAY ENERGIZED

Go to component -> Electric active roll stabilization circuit -> NCA WIRE

nca wiring diagram (22 of 78)

BLK WIRE BLK/RED WIRE BLU WIRE BLU/BRN WIRE BODY DOMAIN CONTROLLER (RIGHT KICK PANEL) BRN WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR ARMREST HEATING DRIVER'S SIDE CONTROL ELECTRONICS FOR ARMREST HEATING DRIVER'S SIDE MIDDLE CONSOLE ARMREST HEATING FRONT PASSENGER'S DOOR ARMREST HEATING FRONT PASSENGER'S SIDE CONTROL ELECTRONICS FOR ARMREST HEATING FRONT PASSENGER'S SIDE MIDDLE CONSOLE ARMREST HEATING FUSE 56 FUSE 57 GRN WIRE HOT W/ TERMINAL NCA WIRE ORG/ WIRE ORG/GRN WIRE RED/GRN WIRE RED/YEL WIRE RIGHT FRONT POWER DISTRIBUTION BOX VIO WIRE WHT WIRE YEL WIRE

Go to component -> Front armrest heating circuit -> NCA WIRE

nca wiring diagram (23 of 78)

BLK WIRE BLU WIRE BODY DOMAIN CONTROLLER BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 74 GRN WIRE GRN/BLU WIRE GRY/BLK WIRE HEATED STEERING WHEEL FUNCTION INDICATOR LIGHT HEATED STEERING WHEEL SWITCH INSTRUMENT PANEL NCA WIRE RED WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX SPORT BUTTON STEERING COLUMN SWITCH CLUSTER STEERING WHEEL HEATING STEERING WHEEL MODULE TOUCH DETECTION ELECTRONICS VIBRATION ACTUATOR WHT/GRY WIRE YEL/BLK WIRE YEL/WHT WIRE

Go to component -> Heated steering wheel circuit -> NCA WIRE

nca wiring diagram (24 of 78)

BRN WIRE BRN/ORG WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SEAT SWITCH CLUSTER DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK FRONT PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK FUSE 64 FUSE 65 FUSE 67 FUSE 68 HOT W/ LEFT FRONT SEAT PNEUMATICS MODULE LEFT FRONT SEAT PNEUMATICS MODULE PUMP NCA WIRE PASSENGER'S DOOR SEAT SWITCH CLUSTER RED WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX RIGHT FRONT SEAT PNEUMATICS MODULE RIGHT FRONT SEAT PNEUMATICS MODULE PUMP WHT WIRE WHT/YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Pneumatics seat circuit -> NCA WIRE

nca wiring diagram (25 of 78)

ALTERNATOR AUXILIARY BATTERY BATTERY BATTERY ELECTRONICS BLK WIRE BLK/GRN WIRE BRN WIRE CAPACITOR BOX COMPUTER DATA LINES SYSTEM CRASH SAFETY MODULE DYNAMIC STABILITY CONTROL (DSC) ELECTRIC FAN CUT-OFF RELAY ELECTROMECHANICAL POWER STEERING ENGINE COMPARTMENT POWER DISTRIBUTION BOX FROM BODY DOMAIN CONTROLLER (DIAGRAM 2 OF 10) FROM REAR POWER DISTRIBUTION BOX (DIAGRAM 5 OF 10) FROM RIGHT FRONT POWER DISTRIBUTION BOX (DIAGRAM 3 OF 10) FRONT ELECTRIC ACTIVE ROLL STABILIZATION FRONT ELECTRIC AUXILIARY HEATER FUSE 300 FUSE 400 FUSE 401 FUSE 402 FUSE 404 FUSE 406 FUSE 408 FUSE 409 FUSE 508 FUSE BOX FUSE BOX 2 GRN WIRE GRY WIRE GRY/GRN WIRE GRY/YEL WIRE INTELLIGENT BATTERY SENSOR JUMP START TERMINAL NCA WIRE POWER CONTROL UNIT (W/O DUAL STORAGE SYSTEM) REAR ELECTRIC ACTIVE ROLL STABILIZATION RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE SAFETY BATTERY TERMINAL GAS GENERATOR STARTER MOTOR SUPPLEMENTARY BATTERY FUSE BOX TO FUSE 504 (DIAGRAM 2 OF 10) TO INTEGRATED SUPPLY MODULE (DIAGRAM 8 OF 10) TRANSFER TERMINAL POINT 2 VIO WIRE WHT WIRE WHT/YEL WIRE

Go to component -> Power distribution circuit (1 of 10) -> NCA WIRE

nca wiring diagram (26 of 78)

AIR FRESHENER BLU/VIO WIRE BRN WIRE CD DRIVE COMPUTER DATA LINES SYSTEM DASHBOARD LOUDSPEAKER LIGHTING DRIVER SEAT MODULE DRIVER'S SEAT ADJUSTMENT SWITCH BLOCK DRIVER'S SIDE CONTROL ELECTRONICS ARMREST HEATING ELECTRICAL STEERING COLUMN ADJUSTMENT ELECTROCHROMIC INTERIOR MIRROR ELECTRONIC TRANSMISSION CONTROL FROM FUSE BOX (DIAGRAM 2 OF 10) FROM RIGHT FRONT POWER DISTRIBUTION BOX (DIAGRAM 5 OF 10) FRONT PASSENGER SEAT MODULE FRONT PASSENGER'S SIDE CONTROL ELECTRONICS ARMREST HEATING FUSE 37 FUSE 46 FUSE 47 FUSE 49 FUSE 50 FUSE 51 FUSE 53 FUSE 54 FUSE 55 FUSE 56 FUSE 57 FUSE 59 FUSE 63 FUSE 73 GRY/YEL WIRE INDEPENDENT AUXILIARY HEATER INSTRUMENT PANEL IONIZER LIN POWER DISTRIBUTION BOX NCA WIRE PASSENGER SIDE SEAT ADJUSTMENT SWITCH BLOCK REAR COMPARTMENT BLOWER MOTOR OUTPUT STAGE REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF LUGGAGE COMPT) RED WIRE RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE RED/YEL WIRE THERMOELECTRIC CUP HOLDER TO AUXILIARY BATTERY (DIAGRAM 1 OF 10) TO FUSE 24 (DIAGRAM 2 OF 10) TO FUSE 60 (DIAGRAM 4 OF 10) TO FUSE 64 (DIAGRAM 10 OF 10) TRANSFER BOX USB PORT 2 W/ SEAT MODULE W/ THERMOELECTRIC CUP W/O SEAT MODULE W/O THERMOELECTRIC CUP WHT/BRN WIRE WIPER MODULE YEL/GRN WIRE

Go to component -> Power distribution circuit (3 of 10) -> NCA WIRE

nca wiring diagram (27 of 78)

4.4L TURBO AUTOMATIC AIR RECIRCULATION CONTROL SENSOR BASIC BODY DOMAIN CONTROLLER BRN WIRE CONTACT FREE TAILGATE OPENING EVALUATION ELECTRONICS ELECTRIC FUEL PUMP CONTROL ELECTRONICS ELECTRICAL EXHAUST FLAP ELECTRICAL EXHAUST FLAP 2 ELECTRO- MECHANICAL POWER STEERING FROM FUSE BOX (DIAGRAM 2 OF 10) FRONT ELECTRIC ACTIVE ROLL STABILIZATION FRONT RADAR SENSOR FUSE 203 FUSE 204 FUSE 207 FUSE 208 FUSE 209 FUSE 210 FUSE 211 FUSE 240 FUSE 279 FUSE 289 GRN WIRE GRN/BRN WIRE GRN/RED WIRE GRN/YEL WIRE LEFT FRONT SIDE NEAR RANGE RADAR SENSOR LEFT REAR NEAR RANGE RADAR SENSOR LIN POWER DISTRIBUTION BOX LONG-DISTANCE RANGE FRONT RADAR SENSOR NCA WIRE NIGHT VISION ELECTRONICS OPTIONAL EQUIPMENT SYSTEM REAR AXLE SLIP ANGLE CONTROL REAR ELECTRIC ACTIVE ROLL STABILIZATION REAR WINDOW HEATING RELAY RED WIRE RED/BRN WIRE RED/GRN WIRE RED/VIO WIRE REGULATED DIFFERENTIAL LOCK RIGHT FRONT SIDE NEAR RANGE RADAR SENSOR RIGHT REAR NEAR RANGE RADAR SENSOR TO FUSE 217 (DIAGRAM 5 OF 10) TO FUSE 218 (DIAGRAM 7 OF 10) TO FUSE 262 (DIAGRAM 8 OF 10) TRAILER MODULE TRAILER SOCKET PREPARATION W/ TRAILER MODULE W/O TRAILER MODULE YEL WIRE

Go to component -> Power distribution circuit (6 of 10) -> NCA WIRE

nca wiring diagram (28 of 78)

AIR CONDITIONING BODY DOMAIN CONTROLLER BRN WIRE COMPUTER DATA LINES SYSTEM FRONT CENTER VENTILATION GRILLE FUSE 231 FUSE 501 FUSE BOX GRN WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES INTERFERENCE SUPPRESSION FILTER INTERFERENCE SUPPRESSION FILTER 2 LIN POWER DISTRIBUTION BOX NCA WIRE ORG/GRN WIRE REAR POWER DISTRIBUTION BOX REAR WINDOW DEFROSTER REAR WINDOW DEFROSTER REJECTOR CIRCUIT REAR WINDOW HEATING BUTTON REAR WINDOW HEATING RELAY RED WIRE WHT WIRE YEL/WHT WIRE

Go to component -> Rear defogger circuit -> NCA WIRE

nca wiring diagram (29 of 78)

AIR CONDITIONING AUTOMATIC REAR AIR CONDITIONING OPERATING FACILITY BLU WIRE BODY DOMAIN CONTROLLER (RIGHT KICK PANEL) BRN WIRE COMPUTER DATA LINES SYSTEM FUSE 253 FUSE 271 GRN WIRE HOT W/ LEFT REAR SEAT HEATING SWITCH NCA WIRE ORG/GRN WIRE REAR DRIVER'S SIDE BACKREST HEATING REAR DRIVER'S SIDE SEAT CUSHION HEATING REAR DRIVER'S SIDE SEAT HEATING MODULE REAR PASSENGER'S SIDE BACKREST HEATING REAR PASSENGER'S SIDE SEAT CUSHION HEATING REAR PASSENGER'S SIDE SEAT HEATING MODULE REAR POWER DISTRIBUTION BOX RED/GRN WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT REAR SEAT HEATING SWITCH VIO/GRY WIRE WHT/GRN WIRE YEL WIRE YEL/BRN WIRE YEL/RED WIRE

Go to component -> Rear heated seats circuit -> NCA WIRE

nca wiring diagram (30 of 78)

BLUETOOTH ANTENNA BRN WIRE COMPUTER DATA COMPUTER DATA LINES SYSTEM DRIVER CAMERA SYSTEM FUSE 212 FUSE 63 GPS ANTENNA GRN WIRE GRN/BLU WIRE GRN/GRY WIRE GRN/RED WIRE GRY WIRE HEAD UNIT HOT W/ INSTRUMENT PANEL LEFT "C" PILLAR) LINES SYSTEM NCA WIRE NIGHT VISION ELECTRONICS REAR POWER DISTRIBUTION BOX REAR SEAT ENTERTAINMENT RECEIVER AUDIO MODULE RED/BLU WIRE RED/BRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT FRONT POWER DISTRIBUTION BOX ROOF ANTENNA (W/O TELEMATICS) (CENTER REAR OF ROOF) SDARS ANTENNA W/ DRIVER CAMERA SYSTEM W/O DRIVER CAMERA SYSTEM WHT WIRE WHT/BLU WIRE WHT/GRY WIRE WHT/RED WIRE WLAN ANTENNA YEL WIRE

Go to component -> Receiver audio module circuit, high level (4 of 6) -> NCA WIRE

Page 3 of 8

1 2 3 4 5 6 7 8

BMW X6 M F96 (2019-2023) nca Wiring diagrams

nca wiring diagram (21 of 78)

List of components:

nca wiring diagram (22 of 78)

List of components:

nca wiring diagram (23 of 78)

List of components:

nca wiring diagram (24 of 78)

List of components:

nca wiring diagram (25 of 78)

List of components:

nca wiring diagram (26 of 78)

List of components:

nca wiring diagram (27 of 78)

List of components:

nca wiring diagram (28 of 78)

List of components:

nca wiring diagram (29 of 78)

List of components:

nca wiring diagram (30 of 78)

List of components:
