BMW X6 M F96 (2019-2023) auxiliary stop light wiring diagram
This page shows the only wiring diagram for the component.auxiliary stop light, which is found in the car BMW X6 M F96 (2019-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
auxiliary stop light wiring diagram (1 of 1)
AUXILIARY STOP LIGHT
AUXILIARY TURN SIGNAL LAMP
BLK WIRE
BLU/YEL WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT PASSENGER VEHICLE EXTERIOR MIRROR
GRN/BLU WIRE
GRY/VIO WIRE
INTERFERENCE SUPPRESSION FILTER
NCA WIRE
PARKING LIGHTS/ DAYTIME RUNNING LIGHTS LED MODULE
RED/YEL WIRE
RIGHT FRONTAL LIGHT ELECTRONICS
RIGHT HEADLIGHT
SIDE LIGHTS/DAYTIME DRIVING LIGHTS
TRAILER BRAKE SYSTEM PLUG CONNECTION
TURN INDICATOR
WHT/RED WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Exterior lamps circuit (3 of 4) -> AUXILIARY STOP LIGHT
