4.4l turbo hybrid, charging circuit, w/ dual storage system for BMW X5 G18 facelift (2023-2024)
4.4l turbo hybrid, charging circuit, w/ dual storage system
ALTERNATOR
AUXILIARY BATTERY
BATTERY
BATTERY ELECTRONICS
BLK WIRE
BLK/GRN WIRE
BRN WIRE
CAPACITOR BOX
COMPUTER DATA LINES SYSTEM
CRASH SAFETY MODULE
DIGITAL MOTOR ELECTRONICS
ENGINE COMPARTMENT POWER DISTRIBUTION BOX
FUSE 244
FUSE 63
GRY WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/
INTELLIGENT BATTERY SENSOR
JUMP START TERMINAL
NCA WIRE
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BRN WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
SAFETY BATTERY TERMINAL GAS GENERATOR
STARTER MOTOR
TRANSFER TERMINAL POINT 2
VIO WIRE
WHT WIRE
