Parking assistant circuit, w/o parking maneuvering assistant & w/ surround view camera for BMW X5 G18 facelift (2023-2024)

Parking assistant circuit, w/o parking maneuvering assistant & w/ surround view camera (1 of 2)

Get access

BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/ORG WIRE BRN/RED WIRE BRN/YEL WIRE FUSE 71 GRN/GRY WIRE GRN/RED WIRE HOT W/ LEFT FRONT CENTER ULTRASONIC SENSOR LEFT FRONT OUTER ULTRASONIC SENSOR LEFT FRONT SIDE PARKING MANEUVERING ASSISTANT ULTRASONIC SENSOR NCA WIRE ORG/ WIRE ORG/GRN WIRE RED/BLU WIRE RELAY ENERGIZED RIGHT FRONT CENTER ULTRASONIC SENSOR RIGHT FRONT OUTER ULTRASONIC SENSOR RIGHT FRONT POWER DISTRIBUTION BOX RIGHT FRONT SIDE PARKING MANEUVERING ASSISTANT ULTRASONIC SENSOR ULTRASONIC CAMERA AUTOMATED PARKING (UCAP) WHT WIRE YEL/BRN WIRE YEL/GRY WIRE

Get access

BRN WIRE BRN/ORG WIRE BRN/RED WIRE CENTER CONSOLE CONTROL COMPUTER DATA LINES SYSTEM FRONT AUTONOMOUS PARKING CAMERA FUSE 32 GRN/GRY WIRE HOT AT ALL TIMES LEFT AUTONOMOUS PARKING CAMERA LEFT REAR CENTER ULTRASONIC SENSOR LEFT REAR OUTER ULTRASONIC SENSOR LEFT REAR ULTRASONIC SENSOR NCA WIRE ORG/ WIRE ORG/GRN WIRE PARKING ASSISTANCE BUTTON REAR AUTONOMOUS PARKING CAMERA RED/BLU WIRE RED/YEL WIRE RIGHT AUTONOMOUS PARKING CAMERA RIGHT FRONT POWER DISTRIBUTION BOX RIGHT REAR CENTER ULTRASONIC SENSOR RIGHT REAR OUTER ULTRASONIC SENSOR RIGHT REAR ULTRASONIC SENSOR WHT WIRE WHT/BLU WIRE WHT/YEL WIRE YEL/BRN WIRE
