Parking assistant circuit, w/ parking maneuvering assistant for BMW X5 G18 facelift (2023-2024)
Parking assistant circuit, w/ parking maneuvering assistant (1 of 2)
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/ORG WIRE
BRN/RED WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FUSE 253
GRN WIRE
GRN/BLK WIRE
GRN/GRY WIRE
GRN/RED WIRE
HOT W/
LEFT FRONT CENTER ULTRASONIC SENSOR
LEFT FRONT OUTER ULTRASONIC SENSOR
LEFT FRONT SIDE PARKING MANEUVERING ASSISTANT ULTRASONIC SENSOR
ORG/ WIRE
ORG/GRN WIRE
ORG/YEL WIRE
PARKING MANEUVERING ASSISTANT
REAR POWER DISTRIBUTION BOX
RED/BLU WIRE
RED/GRN WIRE
RELAY ENERGIZED
RIGHT FRONT CENTER ULTRASONIC SENSOR
RIGHT FRONT OUTER ULTRASONIC SENSOR
RIGHT FRONT SIDE PARKING MANEUVERING ASSISTANT ULTRASONIC SENSOR
YEL/BRN WIRE
YEL/GRY WIRE
Parking assistant circuit, w/ parking maneuvering assistant (2 of 2)
BRN WIRE
BRN/ORG WIRE
BRN/RED WIRE
CENTER CONSOLE CONTROL
COMPUTER DATA LINES SYSTEM
FUSE 32
GRN/GRY WIRE
HOT AT ALL TIMES
LEFT REAR CENTER ULTRASONIC SENSOR
LEFT REAR OUTER ULTRASONIC SENSOR
LEFT REAR ULTRASONIC SENSOR
ORG/ WIRE
ORG/GRN WIRE
PARKING ASSISTANCE BUTTON
RED/BLU WIRE
RED/YEL WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT REAR CENTER ULTRASONIC SENSOR
RIGHT REAR OUTER ULTRASONIC SENSOR
RIGHT REAR ULTRASONIC SENSOR
WHT/BLU WIRE
WHT/YEL WIRE
YEL/BRN WIRE
