Left memory rear seat circuit for BMW X5 G18 facelift (2023-2024)
Left memory rear seat circuit (1 of 2)
ADJUSTMENT DRIVE
BLK WIRE
BLK/BRN WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 255
FUSE 26
FUSE 269
FUSE 67
GRN WIRE
HALL EFFECT SENSOR
HOT AT ALL TIMES
HOT W/
LUGGAGE COMPARTMENT SWITCH BLOCK
REAR DRIVER'S SIDE BACKREST ANGLE ADJUSTMENT DRIVE
REAR DRIVER'S SIDE CONVENIENT ENTRY DRIVE
REAR DRIVER'S SIDE SEAT MODULE
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
SEATS SYSTEM
SERVOMOTOR
W/ OPTIONAL EQUIPMENT
W/O OPTIONAL EQUIPMENT
YEL WIRE
YEL/BRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
Left memory rear seat circuit (2 of 2)
BLK WIRE
BLK/RED WIRE
BLU WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S DOOR SEAT SWITCH CLUSTER
DRIVER'S SIDE REAR SEAT BACKREST FOLDING DOWN SWITCH
GRN WIRE
GRN/BLK WIRE
GRY/WHT WIRE
HALL EFFECT SENSOR
LEFT SEAT BENCH MICROSWITCH
LEFT SEAT BENCH MICROSWITCH 2
REAR DRIVER'S SIDE CONVENIENT ENTRY SWITCH
REAR DRIVER'S SIDE FORWARD/ BACK SEAT ADJUSTMENT DRIVE
REAR DRIVER'S SIDE SEAT ADJUSTMENT SWITCH BLOCK
REAR DRIVER'S SIDE SEAT MODULE
RED/BLK WIRE
RED/GRN WIRE
SEATS SYSTEM
SERVOMOTOR
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
