Instrument cluster circuit for BMW X5 G18 facelift (2023-2024)
Instrument cluster circuit (1 of 2)
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER CAMERA SYSTEM
FUSE 34
FUSE 39
FUSE 73
GRN WIRE
GRN/GRY WIRE
HEAD UNIT
HEAD-UP DISPLAY
HEATED STEERING WHEEL FUNCTION INDICATOR LIGHT
HOT AT ALL TIMES
INSTRUMENT PANEL
NCA WIRE
ORG/ WIRE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT FRONT POWER DISTRIBUTION BOX
W/ DRIVER CAMERA SYSTEM
W/ INSTRUMENT CLUSTER (KOMBI)
W/O DRIVER CAMERA SYSTEM
W/O INSTRUMENT CLUSTER (KOMBI)
WHT WIRE
WHT/BRN WIRE
WHT/GRY WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BLU WIRE
YEL/WHT WIRE
