Rear axle circuit for BMW X5 G05 (2018-2023)
Rear axle circuit
BLU WIRE
BLU/GRY WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
FUSE 204
FUSE 265
FUSE 506
FUSE BOX
GEARBOX OIL TEMPERATURE SENSOR
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT W/
NCA WIRE
ORG/ WIRE
PNK/RED WIRE
PNK/WHT WIRE
POSITION SENSOR
REAR AXLE SLIP ANGLE CONTROL
REAR POWER DISTRIBUTION BOX
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
REGULATED DIFFERENTIAL LOCK
REGULATED DIFFERENTIAL LOCK SERVO MOTOR
RELAY ENERGIZED
VIO WIRE
YEL/GRN WIRE
YEL/VIO WIRE
