Second row seat locking circuit for BMW X5 G05 (2018-2023)
Second row seat locking circuit
BLU WIRE
BLU/WHT WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 26
FUSE 269
FUSE 271
GRN WIRE
GRY/GRN WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL
LEFT REAR SEAT BENCH EMERGENCY RELEASE MICROSWITCH
LEFT SEAT BENCH MICROSWITCH
LEFT SEAT BENCH MICROSWITCH 2
ORG/GRN WIRE
PASS-THROUGH MICROSWITCH
REAR DRIVER'S SIDE SEAT MODULE
REAR FRONT PASSENGER SIDE SEAT MODULE
REAR POWER DISTRIBUTION BOX
RED/BLK WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT FRONT POWER DISTRIBUTION BOX
RIGHT REAR SEAT BENCH EMERGENCY RELEASE MICROSWITCH
RIGHT SEAT BENCH MICROSWITCH
RIGHT SEAT BENCH MICROSWITCH 2
WHT WIRE
YEL/BRN WIRE
YEL/RED WIRE
