Blind spot monitoring circuit, w/ front & rear radar sensors for BMW X5 G05 (2018-2023)
Blind spot monitoring circuit, w/ front & rear radar sensors (1 of 2)
ALL ROUND VISION CAMERA
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
FRONT RADAR SENSOR (IN FRONT LOWER GRILLE)
FUSE 207
FUSE 209
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRY/BLK WIRE
GRY/GRN WIRE
HOT W/
LONG- DISTANCE RANGE FRONT RADAR SENSOR HEATING
LONG-DISTANCE RANGE FRONT RADAR SENSOR
OPTIONAL EQUIPMENT SYSTEM
ORG/GRN WIRE
ORG/YEL WIRE
PARKING MANEUVERING ASSISTANT
PNK/BLU WIRE
REAR POWER DISTRIBUTION BOX
RED/GRN WIRE
RELAY ENERGIZED
W/O SURROUND VIEW CAMERA
WHT/BLU WIRE
WHT/GRY WIRE
YEL/BRN WIRE
Blind spot monitoring circuit, w/ front & rear radar sensors (2 of 2)
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 207
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY WIRE
GRY/BLK WIRE
GRY/GRN WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT W/
LEFT FRONT SIDE NEAR RANGE RADAR SENSOR
LEFT REAR NEAR RANGE RADAR SENSOR
REAR POWER DISTRIBUTION BOX
RELAY ENERGIZED
RIGHT FRONT SIDE NEAR RANGE RADAR SENSOR
RIGHT REAR NEAR RANGE RADAR SENSOR
YEL WIRE
YEL/GRY WIRE
