Headlights circuit for BMW X5 G05 (2018-2023)
Headlights circuit (1 of 2)
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTROCHROMIC INTERIOR MIRROR
FUSE 1
FUSE 3
FUSE 504
FUSE BOX
GRY/VIO WIRE
HEADLIGHT BEAM THROW ADJUSTMENT DRIVE
HIGH BEAM
HIGH BEAM ASSISTANT SENSOR, CONTROL
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
LED MODULE FOR PARKING LAMPS/ DAYTIME RUNNING LIGHTS
LEFT FOG LIGHT
LEFT FRONTAL LIGHT ELECTRONICS
LEFT HEADLIGHT
LOW BEAM
RED WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT FOG LIGHT
SIDE LIGHT/ DAYTIME LIGHT
WHT/RED WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/WHT WIRE
Headlights circuit (2 of 2)
BLU WIRE
BRN WIRE
CENTER CONSOLE CONTROL
COMPUTER DATA LINES SYSTEM
GRY/VIO WIRE
HEADLIGHT BEAM THROW ADJUSTMENT DRIVE
HIGH BEAM
LIGHT OPERATING UNIT NIGHT VISION BUTTON
LOW BEAM
PARKING BRAKE BUTTON
RAIN/LIGHT/SOLAR CONDENSATION SENSOR
RED/GRY WIRE
RED/YEL WIRE
RIGHT FRONTAL LIGHT ELECTRONICS
RIGHT HEADLIGHT
WHT/BLU WIRE
WHT/YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
