BMW X5 G05 (2018-2023) side light/ daytime light Wiring diagram
This page shows the only wiring diagram for the component.side light/ daytime light, which is found in the car BMW X5 G05 (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram side light/ daytime light (1 of 1)
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTROCHROMIC INTERIOR MIRROR
FUSE 1
FUSE 3
FUSE 504
FUSE BOX
GRY/VIO WIRE
HEADLIGHT BEAM THROW ADJUSTMENT DRIVE
HIGH BEAM
HIGH BEAM ASSISTANT SENSOR, CONTROL
HOT AT ALL TIMES
HOT W/ BI-STABLE RELAY ENERGIZED
LED MODULE FOR PARKING LAMPS/ DAYTIME RUNNING LIGHTS
LEFT FOG LIGHT
LEFT FRONTAL LIGHT ELECTRONICS
LEFT HEADLIGHT
LOW BEAM
RED WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT FOG LIGHT
SIDE LIGHT/ DAYTIME LIGHT
WHT/RED WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
YEL/WHT WIRE
Go to component -> Headlights circuit (1 of 2) -> SIDE LIGHT/ DAYTIME LIGHT
