BMW X5 G05 (2018-2023) night vision button wiring diagram
This page shows the only wiring diagram for the component.night vision button, which is found in the car BMW X5 G05 (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
night vision button wiring diagram (1 of 1)
BLU WIRE
BODY DOMAIN CONTROLLER
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 1
FUSE 211
GRN WIRE
GRN/RED WIRE
GRY WIRE
HEAD UNIT
HOT W/ BI-STABLE RELAY ENERGIZED
LIGHT OPERATING UNIT
NCA WIRE
NIGHT VISION BUTTON
NIGHT VISION CAMERA
NIGHT VISION ELECTRONICS
ORG/ WIRE
REAR POWER DISTRIBUTION BOX
RED/YEL WIRE
RELAY ENERGIZED
WHT WIRE
YEL/BLK WIRE
YEL/GRN WIRE
Go to component -> Electronic night vision circuit -> NIGHT VISION BUTTON
