BMW X5 G05 (2018-2023) light operating unit night vision button Wiring diagram
This page shows the only wiring diagram for the component.light operating unit night vision button, which is found in the car BMW X5 G05 (2018-2023). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light operating unit night vision button (1 of 1)
BLU WIRE
BRN WIRE
CENTER CONSOLE CONTROL
COMPUTER DATA LINES SYSTEM
GRY/VIO WIRE
HEADLIGHT BEAM THROW ADJUSTMENT DRIVE
HIGH BEAM
LIGHT OPERATING UNIT NIGHT VISION BUTTON
LOW BEAM
PARKING BRAKE BUTTON
RAIN/LIGHT/SOLAR CONDENSATION SENSOR
RED/GRY WIRE
RED/YEL WIRE
RIGHT FRONTAL LIGHT ELECTRONICS
RIGHT HEADLIGHT
WHT/BLU WIRE
WHT/YEL WIRE
YEL/GRN WIRE
YEL/GRY WIRE
Go to component -> Headlights circuit (2 of 2) -> LIGHT OPERATING UNIT NIGHT VISION BUTTON
