3.0l twin turbo, rear axle circuit for BMW X5 E70 facelift (2010-2013)
3.0l twin turbo, rear axle circuit
ACTIVE STEERING (BEHIND LEFT FRONT WHEEL)
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE
GRN/RED WIRE
HOT AT ALL TIMES REAR POWER DISTRIBUTION BOX (RIGHT SIDE
HOT W/ TERMINAL
LEFT ACTUATOR MOTOR
LEFT MOTOR POSITION SENSOR
LEFT OIL TEMPERATURE SENSOR
MANAGEMENT (ICM)
NCA WIRE
OF REAR COMPT)
ORG/ WIRE
REAR AXLE TRANSVERSE TORQUE DISTRIBUTION
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/WHT WIRE
RIGHT ACTUATOR MOTOR
RIGHT MOTOR POSITION SENSOR
RIGHT OIL TEMPERATURE SENSOR
W/ ACTIVE STEERING
W/O ACTIVE STEERING
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
YEL/WHT WIRE
