Second row seat locking circuit for BMW X5 E70 facelift (2010-2013)
Second row seat locking circuit
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
FUSE
GRN WIRE
GRN/BLK WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL UNIT
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
JUNCTION BOX ELECTRONICS
LEFT REAR BENCH SEAT SWITCH 1
LEFT REAR BENCH SEAT SWITCH 2
LEFT REAR BENCH SEAT SWITCH 3
LEFT REAR BENCH SEAT SWITCH 4
ORG/GRN WIRE
RIGHT REAR BENCH SEAT SWITCH
