BMW X5 E70 facelift (2010-2013) Rear heated seats circuit, with rear a/c

BLK WIRE BLK/BRN WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES HOT W/ HOT W/ TERMINAL 15 RELAY ENERGIZED LEFT REAR SEAT BACKREST HEATING LEFT REAR SEAT CUSHION HEATING LEFT REAR SEAT HEATING MODULE ORG/GRN WIRE POWER DISTRIBUTION SYSTEM REAR COMPARTMENT AIR CONDITIONING CONTROL MODULE REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) RED/BLU WIRE RED/VIO WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT REAR SEAT BACKREST HEATING RIGHT REAR SEAT CUSHION HEATING RIGHT REAR SEAT HEATING MODULE W/ THIRD ROW SEATS WHT/BLU WIRE WHT/GRY WIRE YEL WIRE
