Front heated seats circuit, without memory for BMW X5 E70 facelift (2010-2013)
Front heated seats circuit, without memory
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SEAT BACKREST HEATING
DRIVER'S SEAT CUSHION HEATING
DRIVER'S SEAT HEATING MODULE
FUSE
GRN WIRE
GRN/VIO WIRE
HEATING/ AIR CONDITIONING SYSTEM
HOT W/ BI-STABLE RELAY (VARIANT-DEPENDENT) ENERGIZED
HOT W/ TERMINAL 15 RELAY ENERGIZED
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
JUNCTION BOX ELECTRONICS
ORG/GRN WIRE
PASSENGER'S SEAT BACKREST HEATING
PASSENGER'S SEAT CUSHION HEATING
PASSENGER'S SEAT HEATING MODULE
POWER DISTRIBUTION SYSTEM
REAR POWER DISTRIBUTION BOX FUSE
RED/BRN WIRE
RED/GRN WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
YEL WIRE
