All around vision camera circuit for BMW X5 E70 facelift (2010-2013)
All around vision camera circuit
ALL-ROUND VISION CAMERA (UNDER LEFT SIDE OF DASH)
BLU WIRE
BRN WIRE
CAR INFORMATION COMPUTER
COMPUTER DATA LINES SYSTEM
FUSE 114 DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT)
GRN WIRE
HOT W/ TERMINAL 15 RELAY ENERGIZED
LEFT BUMPER CAMERA
LEFT EXTERIOR MIRROR CAMERA
NCA WIRE
ORG/ WIRE
ORG/GRN WIRE
REAR POWER
RED/GRN WIRE
REVERSING CAMERA (RIGHT SIDE OF TAILGATE)
RIGHT BUMPER CAMERA
RIGHT EXTERIOR MIRROR CAMERA
W/O MMC W/ MMC
WHT WIRE
