3rd row seat heater circuit for BMW X5 E70 facelift (2010-2013)
3rd row seat heater circuit
17 7 14 CAN H CAN L
AIR DISTRIBUTION MICROSWITCH
AUXILIARY HEATER CONTROL MODULE
BLK WIRE
BLK/WHT WIRE
BLOWER BUTTON
BLOWER MOTOR
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE
GRN WIRE
HEATING/AIR CONDITIONING SYSTEM
HOT AT ALL TIMES REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT)
NCA WIRE
ORG/GRN WIRE
REAR ELECTRIC AUXILIARY HEATER
RED WIRE
RED/GRN WIRE
VIO WIRE
WHT WIRE
YEL WIRE
