BMW X5 E70 facelift (2010-2013) outlet 11 charging socket Wiring diagram

3.0L TWIN TURBO W/O VOICE RECOGNITION ALL ROUND VISION CAMERA ANTI-THEFT SYSTEM BLK WIRE BLU WIRE BOOT LID LIFT BRN WIRE DRIVER'S CAMERA- SEAT BASED HEATING DRIVER SUPPORT MODULE SYSTEMS DRIVER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE DRIVER'S SEAT ADJUSTMENT SWITCH ELECTRIC FAN CUTOUT RELAY EXCEPT 3.0L TWIN TURBO DIESEL EXHAUST FLAP (4.4L TWIN TURBO) FROM FROM FUSE FRONT CIGAR LIGHTER FUEL TANK LEAKAGE DIAGNOSTIC MODULE FUSE FUSE FUSE GRN WIRE GRY WIRE LEFT REAR AUTOMATIC SOFT-CLOSE DRIVE LUGGAGE COMPART- MENT REAR SOCKET OUTLET 11 CHARGING SOCKET PARK DISTANCE CONTROL (PDC) PASSENGER'S DOOR AUTOMATIC SOFT-CLOSE DRIVE PASSENGER'S SEAT ADJUST- MENT SWITCH PASSENGER'S SEAT HEATING MODULE REAR AXLE TRANSVERSE TORQUE DISTRIBUTION (QMVH) REAR CIGAR- ETTE LIGHTER REAR COMPARTMENT AIR CONDIT- TIONING CONTROL MODULE REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) TO FUSE REAR SOCKET OUTLET RED WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RIGHT REAR AUTOMATIC SOFT-CLOSE DRIVE RIGHT REAR LEFT REAR SEAT SEAT HEATING HEATING MODULE MODULE ROOF FUNCTION CONTROL CENTER ROOF VIDEO MODULE OR VOICE FUNCTION CONTROL CONTROL SYSTEM CENTER (IF EQUIPPED) SEATS TERM 15 POWER SAVING RELAY TERMINAL 15 RELAY TO FUSE TRAILER SOCKET TRAILER TRAILER MODULE MODULE TRANSFER BOX CONTROL MODULE VERTICAL DYNAMICS MANAGEMENT VIO WIRE W/ POWER W/O POWER OPERATED OPERATED TOWING TOWING HATCH HATCH W/ REAR SEAT AIR CONDITIONING W/ VOICE RECOGNITION W/O VOICE RECOGNITION W/O REAR COMPARTMENT AIR CONDITIONING W/O REAR SEAT AIR CONDITIONING WHT WIRE YEL WIRE
