BMW X5 E70 facelift (2010-2013) active video switch Wiring diagram
This page shows the only wiring diagram for the component.active video switch, which is found in the car BMW X5 E70 facelift (2010-2013). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram active video switch (1 of 1)
ACTIVE VIDEO SWITCH
BLU WIRE
BRN WIRE
BRN/BLK WIRE
CCC/M-ASK
CENTRAL INFORMATION DISPLAY
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
NCA WIRE
ORG/ WIRE
ORG/GRN WIRE
OUTSIDE MIRROR CAMERA
PASSENGER'S SIDE OUTSIDE MIRROR
RED WIRE
RED/YEL WIRE
RELAY ENERGIZED JUNCTION BOX (UNDER RIGHT SIDE OF DASH) FUSE
WHT WIRE
YEL WIRE
Go to component -> Outside mirror camera circuit -> ACTIVE VIDEO SWITCH
