Car Wiring Diagrams for Driver"s memory seat circuit, without lumbar support for BMW X5 E70 (2006-2010)

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 PINS: 17-26 NOT USED BLK/BRN WIRE BLK/VIO WIRE BLK/YEL WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/RED WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER'S SEAT ADJUSTMENT SWITCH DRIVER'S SEAT ANGLE ADJUSTMENT DRIVE DRIVER'S SEAT BACKREST ANGLE ADJUSTMENT DRIVE DRIVER'S SEAT FORWARD/ BACKWARD ADJUSTMENT DRIVE DRIVER'S SEAT HEAD RESTRAINT ADJUSTMENT DRIVE DRIVER'S SEAT HEIGHT ADJUSTMENT DRIVE DRIVER'S SEAT MODULE GRN WIRE GRN/BLK WIRE GRN/WHT WIRE GRN/YEL WIRE GRY/GRN WIRE GRY/WHT WIRE NCA WIRE ORG/GRN WIRE RED/BRN WIRE RED/YEL WIRE RELAY ENERGIZED REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) FUSE SEATS SYSTEM (HEATED SEAT CIRCUIT) SEATS SYSTEM (SEAT VENTILATION CIRCUIT) VIO/GRN WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL/BRN WIRE YEL/RED WIRE
