BMW X5 E70 (2006-2010) w/ vertical dynamics w/o vertical dynamics Wiring diagram
This page shows the only wiring diagram for the component.w/ vertical dynamics w/o vertical dynamics, which is found in the car BMW X5 E70 (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ vertical dynamics w/o vertical dynamics (1 of 1)
AIR SUPPLY SYSTEM
AIR SUSPEN- SION COMPRESSOR RELAY
BLU/BLK WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONIC RIDE HEIGHT CONTROL (RIGHT SIDE OF REAR COMPT)
FUSE
GRN WIRE
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT REAR LEVEL SENSOR
ORG/GRN WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/YEL WIRE
RELAY ENERGIZED REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) FUSE
RIGHT REAR LEVEL SENSOR
W/ VERTICAL DYNAMICS W/O VERTICAL DYNAMICS
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRY WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRY WIRE
Go to component: -> Air suspension circuit -> W/ VERTICAL DYNAMICS W/O VERTICAL DYNAMICS
