BMW X5 E70 (2006-2010) pass- enger door exit light Wiring diagram

This page shows the only wiring diagram for the component.pass- enger door exit light, which is found in the car BMW X5 E70 (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram pass- enger door exit light (1 of 1)

Wiring diagram pass- enger door exit light for BMW X5 E70 (2006-2010)

Get access

BLK/BLU WIRE BLK/WHT WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/WHT WIRE GRN WIRE GRN/WHT WIRE GRY/RED WIRE INTERIOR LIGHT) LEFT B-PILLAR INTERIOR LIGHT LEFT FRONT MAKE- UP MIRROR LIGHT LEFT REAR DOOR EXIT LIGHT DRIVER'S DOOR EXIT LIGHT LEFT REAR INTERIOR LIGHT LIGHT TOP MAP READING LIGHT ORG/GRN WIRE PASS- ENGER DOOR EXIT LIGHT RED/BLK WIRE RED/BLU WIRE RED/BRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT B-PILLAR INTERIOR LIGHT RIGHT FRONT MAKE- UP MIRROR LIGHT RIGHT REAR DOOR EXIT LIGHT RIGHT REAR INTERIOR LIGHT ROOF FUNCTION CONTROL CENTER W/ LIGHT PACKAGE W/ LIGHT PACKAGE W/O LIGHT PACKAGE W/O LIGHT PACKAGE

Go to component: -> Courtesy lamps circuit (2 of 2) -> PASS- ENGER DOOR EXIT LIGHT
