BMW X5 E70 (2006-2010) left head air bag inflator assembly Wiring diagram
This page shows the only wiring diagram for the component.left head air bag inflator assembly, which is found in the car BMW X5 E70 (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left head air bag inflator assembly (1 of 1)
BLK WIRE
BLK/GRN WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/VIO/YEL WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
CAR ACCESS SYSTEM
CENTER ROOF FUNCTION CONTROL
CRASH SAFETY MODULE (RIGHT SIDE OF SHIFTER ASSEMBLY
DRIVER'S SEAT BELT BUCKLE CONTACT
DRIVER'S SEAT BELT TENSIONER GENERATOR
DRIVER'S SEAT OCCUPANCY ELECTRONICS
GRN WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
LEFT FRONT SIDE AIR BAG INFLATOR ASSEMBLY
LEFT HEAD AIR BAG INFLATOR ASSEMBLY
NCA WIRE
ORG/GRN WIRE
PASSENGER'S SEAT BELT BUCKLE CONTACT
PASSENGER'S SEAT BELT TENSIONER GENERATOR
PASSENGER'S SEAT OCCUPANCY DETECTION
RED WIRE
RIGHT FRONT SIDE AIR BAG INFLATOR ASSEMBLY
RIGHT HEAD AIR BAG INFLATOR ASSEMBLY
SAFETY BATTERY TERMINAL GENERATOR
VIO WIRE
VIO/BLU WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component: -> Supplemental restraints circuit (3 of 3) -> LEFT HEAD AIR BAG INFLATOR ASSEMBLY
