BMW X5 E70 (2006-2010) left boot lid lift drive unit Wiring diagram
This page shows the only wiring diagram for the component.left boot lid lift drive unit, which is found in the car BMW X5 E70 (2006-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left boot lid lift drive unit (1 of 1)
AUTO- MATIC SOFT- CLOSE RELAY
AUTOMATIC TRUNK LID INTERIOR SWITCH
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BOTTOM BOOT LID CONTACT SWITCH
BRN WIRE
BRN/BLK WIRE
CENTRAL LOCKING DRIVE FUEL FILLER FLAP
CENTRAL LOCKING DRIVE, TRUNK LID
COMPUTER DATA LINES SYSTEM
ELECTRONICS JUNCTION BOX
FUSE
GRN WIRE
GRN/BLK WIRE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
JUNCTION BOX (UNDER RIGHT SIDE OF DASH)
LEFT BOOT LID LIFT DRIVE UNIT
NCA WIRE
ORG/GRN WIRE
REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT)
RED/BRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RELAY ENERGIZED
RIGHT BOOT LID LIFT DRIVE UNIT
TRUNK LID LIFT
TRUNK LID SWITCH
TRUNK LID/TAILGATE AUTOMATIC SOFT-CLOSE DRIVE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/RED WIRE
Go to component: -> Trunk & fuel door release circuit -> LEFT BOOT LID LIFT DRIVE UNIT
