3.0L 4.8L ANTENNA DIVERSITY ANTI-LOCK BRAKES SYSTEM ANTI-THEFT SYSTEM (ANTI-THEFT CIRCUIT) BLK WIRE BLK/GRN WIRE BLK/VIO WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE LIGHT SWITCH BRN WIRE BRN/BLK WIRE BRN/GRY WIRE CAR ACCESS SYSTEM (UNDER LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM CRASH SAFETY MODULE DIGITAL MOTOR ELECTRONIC (DME) CONTROL MODULE DRIVER'S SEAT OCCUPANCY ELECTRONICS FOOTWELL MODULE GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRY WIRE NCA WIRE ORG/GRN WIRE PASSENGER'S SEAT OCCUPANCY DETECTION RED WIRE RED/BLU WIRE RED/VIO WIRE STARTING/CHARGING SYSTEM TELEPHONE TRANSCEIVER TRANSMISSION CONTROL MODULE VIO WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE YEL WIRE YEL/BRN WIRE YEL/VIO WIRE

Go to component -> Access/start circuit (1 of 3) -> GRN WIRE

Wiring diagram grn (12 of 93)

Get access

BLU/YEL WIRE BRN WIRE DRIVER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE FUSE GRN WIRE HOT AT ALL TIMES HOT W/ BI-STABLE RELAY ENERGIZED JUNCTION BOX (UNDER RIGHT SIDE OF DASH) FUSE LEFT REAR OUTER DOOR HANDLE ELECTRONIC MODULE PASSENGER'S SIDE OUTER DOOR HANDLE ELECTRONIC MODULE REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) FUSE RED WIRE RED/BLU WIRE RED/VIO WIRE RED/YEL WIRE RELAY RIGHT REAR OUTER DOOR HANDLE ELECTRONIC MODULE TERMINAL TERMINAL 15 RELAY WHT WIRE

Go to component -> Access/start circuit (2 of 3) -> GRN WIRE

Wiring diagram grn (13 of 93)

Get access

BLU/GRY WIRE BLU/YEL WIRE BRN WIRE COMFORT ACCESS CONTROL MODULE (RIGHT SIDE OF REAR COMPT) COMPUTER DATA LINES SYSTEM FRONT INTERIOR ANTENNA CENTRE CONSOLE GRN WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE LUGGAGE COMPARTMENT 1 INNER ANTENNA LUGGAGE COMPARTMENT 2 INNER ANTENNA ORG/GRN WIRE REAR FENDER AERIAL REAR INTERIOR ANTENNA CENTRE CONSOLE RED WIRE RED/YEL WIRE SLIDE-IN COMPARTMENT START-STOP BUTTON WHT WIRE WHT/BLK WIRE WHT/GRN WIRE

Go to component -> Access/start circuit (3 of 3) -> GRN WIRE

Wiring diagram grn (14 of 93)

Get access

AIR SUPPLY SYSTEM AIR SUSPEN- SION COMPRESSOR RELAY BLU/BLK WIRE BLU/GRY WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM ELECTRONIC RIDE HEIGHT CONTROL (RIGHT SIDE OF REAR COMPT) FUSE GRN WIRE HOT AT ALL TIMES JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT REAR LEVEL SENSOR ORG/GRN WIRE RED/BLK WIRE RED/GRN WIRE RED/YEL WIRE RELAY ENERGIZED REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) FUSE RIGHT REAR LEVEL SENSOR W/ VERTICAL DYNAMICS W/O VERTICAL DYNAMICS WHT/BLK WIRE WHT/BLU WIRE WHT/GRY WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRY WIRE

Go to component -> Air suspension circuit -> GRN WIRE

Wiring diagram grn (15 of 93)

Get access

AUTOMATIC TRUNK LID INTERIOR SWITCH BLK WIRE BLU WIRE BRN BRN WIRE BRN WIRE BRN/BLK WIRE BRN/GRY WIRE BRN/WHT WIRE CAR ACCESS SYSTEM CENTRAL LOCKING DRIVE, TRUNK LID GLOVE COMPARTMENT 2 UNLOCK DRIVE UNIT GLOVE COMPARTMENT LIGHT GLOVE COMPARTMENT UNLOCK DRIVE UNIT GRN WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE HAZARD WARNING SWITCH HOOD CONTACT SWITCH RED WIRE RED/BRN WIRE RED/WHT WIRE SYSTEM LOCK, REAR DRIVER'S SIDE SYSTEM LOCK, REAR PASSENGER'S SIDE TRUNK LID SWITCH TRUNK LID/TAILGATE AUTOMATIC SOFT-CLOSE DRIVE TRUNK, TAILGATE, FUEL DOORS SYSTEM VIO/GRN WIRE WHT WIRE YEL/BLK WIRE YEL/RED WIRE

Go to component -> Anti-theft & central locking circuit (2 of 2) -> GRN WIRE

Wiring diagram grn (16 of 93)

Get access

BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/RED WIRE BLU/YEL WIRE BRAKE LGHT BRN/BLK WIRE BRN/BLU WIRE FOOTWELL MODULE (LEFT SIDE OF LEFT FOOTWELL) FUSE GRN WIRE GRN/BLK WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/RED WIRE GRY/WHT WIRE HARD SW SIG LED AUTO H BEAM LED HAZRD FLASHR HEADLGHT HEIGHT CNTRL HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HOT AT ALL TIMES INTERIOR LGHTS JUNCTION BOX (UNDER RIGHT SIDE OF DASH) L BEAM SIG ORG/GRN WIRE PARKING LGHT REVERSE LGHT RED WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE TERM 30 FOG LGHT SIG H BEAM SIG WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE

Go to component -> Body control modules circuit (1 of 2) -> GRN WIRE

Wiring diagram grn (17 of 93)

Get access

10 5 9 PT_CAN L PT_CAN H WAKE-UP 16 9 13 PT_CAN L PT_CAN H WAKE-UP 19 18 13 26 K_CAN L K_CAN H F_CAN H F_CAN L 19 35 26 WAKE-UP K_CAN H K_CAN L 2 3 1 F_CAN L F_CAN H 2 6 9 2 6 9 PT_CAN L PT_CAN H WAKE-UP 21 1 14 17 2 3 TD SIG PT_CAN L PT_CAN H 28 43 1 44 29 PT_CAN L PT_CAN H WAKE-UP F_CAN H F_CAN L 3 4 5 PT_CAN L PT_CAN H WAKE-UP 4 13 12 3 1 PT_CAN L PT_CAN H F_CAN H F_CAN L WAKE-UP 4.8L 3.0L 40 25 14 38 23 1 PT_CAN H PT_CAN L WAKE-UP F_CAN H F_CAN L 46 45 43 44 K_CAN H K_CAN L F_CAN L F_CAN H 6 12 F_CAN L F_CAN H 7 6 3 PT_CAN L PT_CAN H WAKE-UP 9 8 3 5 6 PT_CAN L PT_CAN H WAKE-UP F_CAN H F_CAN L ACTIVE STEERING BLK WIRE BLK/BLU WIRE BLU/RED WIRE BRN WIRE BRN/BLK WIRE CAR ACCESS SYSTEM CRASH SAFETY MODULE DIGITAL MOTOR ELECTRONICS (DME) CONTROL MODULE DSC SENSOR DYNAMIC DRIVE DYNAMIC STABILITY CONTROL (DSC) D_CAN H D_CAN L ELECTRONICS JUNCTION BOX FOOTWELL MODULE FUEL PUMP CONTROL (EKPS) GEAR SELECTOR SWITCH GRN WIRE GRN/RED WIRE INTELLIGENT BATTERY SENSOR JUNCTION BOX (UNDER RIGHT SIDE OF DASH) ORG/GRN WIRE PARKING BRAKE CONTROL MODULE PT_CAN H PT_CAN L RED WIRE RED/WHT WIRE RELAY ENERGIZED REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) FUSE STEERING COLUMN SWITCH CLUSTER TRANSFER BOX CONTROL MODULE TRANSMISSION CONTROL UNIT VERTICAL DYNAMICS MANAGEMENT WAKE-UP WHT/BLU WIRE WHT/YEL WIRE YEL WIRE

Go to component -> Computer data lines circuit (1 of 2) -> GRN WIRE

Wiring diagram grn (18 of 93)

Get access

1 11 K_CAN H K_CAN L 1 2 K_CAN H K_CAN L 1 6 K_CAN H K_CAN L 11 9 K_CAN H K_CAN L 14 1 K_CAN H K_CAN L 15 2 K_CAN H K_CAN L 17 11 K_CAN H K_CAN L 17 7 K_CAN H K_CAN L 18 19 K_CAN H K_CAN L 18 2 K_CAN L K_CAN H 2 8 K_CAN H K_CAN L 24 25 K_CAN H K_CAN L 3 4 K_CAN H K_CAN L 5 2 K_CAN L K_CAN H 5 6 K_CAN H K_CAN L 5 6 K_CAN L K_CAN H 6 5 K_CAN H K_CAN L 6 5 K_CAN L K_CAN H 6 7 K_CAN H K_CAN L ACTIVE VIDEO SWITCH AMPLIFIER CCC/M-ASK CENTRAL INFORMATION DISPLAY COMFORT ACCESS CONTROL MODULE CONTROLLER DRIVER'S SEAT MODULE ELECTROCHROMIC INTERIOR REAR VIEW MIRROR ELECTRONIC RIDE HEIGHT CONTROL GRN WIRE HEAD-UP DISPLAY HEATING/AIR CONDITIONING SYSTEM INSTRUMENT CLUSTER CONTROL MODULE ORG/GRN WIRE PARK DISTANCE CONTROL (PDC) PASSENGER'S SEAT MODULE REAR COMPARTMENT AIR CONDITIONING CONTROL MODULE REAR COMPARTMENT DISPLAY REAR SEAT ENTERTAINMENT REVERSING CAMERA ROOF FUNCTION CONTROL CENTER TIRE PRESSURE CONTROL (RDC) TRAILER MODULE

Go to component -> Computer data lines circuit (2 of 2) -> GRN WIRE

Wiring diagram grn (19 of 93)

Get access

"A" PILLAR) OF RIGHT (BOTTOM BLK/BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM FUSE GRN WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT REAR FOOTWELL TEMPERATURE SENSOR LEFT REAR VENTILATION TEMPERATURE SENSOR ORG/GRN WIRE REAR COMPARTMENT AIR CONDITIONING CONTROL MODULE REAR COMPARTMENT MIXING FLAP POTENTIOMETER RED/BLU WIRE RELAY ENERGIZED RIGHT REAR FOOTWELL TEMPERATURE SENSOR RIGHT REAR VENTILATION TEMPERATURE SENSOR SEATS SYSTEM WHT/BLK WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/RED WIRE YEL/BLU WIRE YEL/GRN WIRE

Go to component -> Rear heater & a/c circuit (1 of 2) -> GRN WIRE

Wiring diagram grn (20 of 93)

Get access

1 3 10 STPPR GRD LIN BUS STPPR PWR 17 7 CAN H CAN L BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM FUSE GRN WIRE HEATING/AIR CONDITIONING SYSTEM HOT AT ALL TIMES HOT AT ALL TIMES REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) LEFT REAR ELECTRIC AUXILIARY HEATER LEFT REAR FOOTWELL FLAP MOTOR (LEFT SIDE OF CENTER OF DASH) LEFT REAR STRATIFYING AIR FLAP MOTOR (LEFT SIDE OF CENTER OF DASH) ORG/GRN WIRE REAR COMPARTMENT BLOWER MOTOR RED WIRE RED/BLU WIRE RED/GRN WIRE RIGHT REAR ELECTRIC AUXILIARY HEATER RIGHT REAR FOOTWELL FLAP MOTOR (RIGHT SIDE OF CENTER OF DASH) RIGHT REAR STRATIFYING AIR FLAP MOTOR (RIGHT SIDE OF CENTER OF DASH) WHT/BRN WIRE

Go to component -> Rear heater & a/c circuit (2 of 2) -> GRN WIRE
