Wiring diagram computer data lines system (31 of 56)

Wiring diagram computer data lines system for BMW X5 E70 (2006-2010)

Get access

BLK/BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM ELECTROCHROMIC INTERIOR REAR VIEW MIRROR ELECTRONICS JUNCTION BOX FUSE GRN WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) ORG/GRN WIRE RED/GRN WIRE RELAY ENERGIZED ROOF FUNCTION CONTROL CENTER

Go to component: -> Electrochromic mirror circuit -> COMPUTER DATA LINES SYSTEM

Wiring diagram computer data lines system (32 of 56)

Wiring diagram computer data lines system for BMW X5 E70 (2006-2010)

Get access

BLK/BRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM DRIVER'S SEAT BACKREST HEATING DRIVER'S SEAT CUSHION HEATING DRIVER'S SEAT MODULE ELECTRONICS JUNCTION BOX FUSE GRN WIRE HEATING, A/C SYSTEM JUNCTION BOX (UNDER RIGHT SIDE OF DASH) NOT USED ORG/GRN WIRE REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) RED/BRN WIRE RELAY ENERGIZED W/ MULTI- FUNCTION SEATS W/O MULTI- FUNCTION SEATS WHT/BLU WIRE

Go to component: -> Front heated seats circuit, with memory seats (1 of 2) -> COMPUTER DATA LINES SYSTEM

Wiring diagram computer data lines system (33 of 56)

Wiring diagram computer data lines system for BMW X5 E70 (2006-2010)

Get access

BLK/BRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM DRIVER'S BACKREST CUSHION HEATING DRIVER'S SEAT BACKREST HEATING DRIVER'S SEAT CUSHION HEATING ELECTRONICS JUNCTION BOX FUSE GRN WIRE HEATING, A/C SYSTEM JUNCTION BOX (UNDER RIGHT SIDE OF DASH) NOT USED ORG/GRN WIRE PASSENGER'S SEAT MODULE REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) RED/GRN WIRE RELAY ENERGIZED W/ MULTI- FUNCTION SEATS W/O MULTI- FUNCTION SEATS WHT/BLU WIRE

Go to component: -> Front heated seats circuit, with memory seats (2 of 2) -> COMPUTER DATA LINES SYSTEM

Wiring diagram computer data lines system (34 of 56)

Wiring diagram computer data lines system for BMW X5 E70 (2006-2010)

Get access

BLK WIRE BLK/YEL WIRE BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S SEAT BACKREST HEATING DRIVER'S SEAT CUSHION HEATING DRIVER'S SEAT HEATING MODULE ELECTRONICS JUNCTION BOX FUSE GRN WIRE GRN/VIO WIRE HEATING, A/C SYSTEM HOT IN RUN OR START JUNCTION BOX (UNDER RIGHT SIDE OF DASH) ORG/GRN WIRE PASSENGER'S SEAT BACKREST HEATING PASSENGER'S SEAT CUSHION HEATING PASSENGER'S SEAT HEATING MODULE REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) RED/BRN WIRE RED/GRN WIRE RELAY ENERGIZED WHT WIRE WHT/BLU WIRE WHT/GRY WIRE YEL WIRE

Go to component: -> Front heated seats circuit, without memory seats -> COMPUTER DATA LINES SYSTEM

Wiring diagram computer data lines system (35 of 56)

Wiring diagram computer data lines system for BMW X5 E70 (2006-2010)

Get access

BLK WIRE BLK/WHT WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM ELECTRONICS JUNCTION BOX FUSE GRN WIRE GRN/RED WIRE GRY/WHT WIRE HEATER SWITCH RIGHT STEERING WHEEL MULTIFUNCTION SWITCH BLOCK HEATING/ AIR CONDITIONING SYSTEM JUNCTION BOX (UNDER RIGHT SIDE OF DASH) NCA WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RELAY ENERGIZED RELAY ENERGIZED REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) FUSE STEERING COLUMN SWITCH CENTER STEERING WHEEL HEATING CONTROL MODULE STEERING WHEEL HEATING TEMPERATURE SENSOR VOLUTE SPRING WHT/BLU WIRE WHT/YEL WIRE YEL WIRE

Go to component: -> Heated steering wheel circuit -> COMPUTER DATA LINES SYSTEM

Wiring diagram computer data lines system (36 of 56)

Wiring diagram computer data lines system for BMW X5 E70 (2006-2010)

Get access

BLK/BLU WIRE BLK/YEL WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/VIO WIRE GRN/WHT WIRE HOT WITH TERMINAL 15 RELAY ENERGIZED JUNCTION BOX (UNDER RIGHT SIDE OF DASH) LEFT FRONT CENTER ULTRASONIC SENSOR (FRONT BUMPER) LEFT FRONT ULTRASONIC SENSOR (FRONT BUMPER) LEFT REAR CENTER ULTRASONIC SENSOR (REAR BUMPER) LEFT REAR ULTRASONIC SENSOR (REAR BUMPER) ORG/GRN WIRE PARK DISTANCE CONTROL (PDC) (RIGHT SIDE OF REAR COMPT) RIGHT FRONT CENTER ULTRASONIC SENSOR (FRONT BUMPER) RIGHT FRONT ULTRASONIC SENSOR (FRONT BUMPER) RIGHT REAR CENTER ULTRASONIC SENSOR (REAR BUMPER) RIGHT REAR ULTRASONIC SENSOR (REAR BUMPER) WHT WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/GRY WIRE

Go to component: -> Parking assistant circuit -> COMPUTER DATA LINES SYSTEM

Wiring diagram computer data lines system (37 of 56)

Wiring diagram computer data lines system for BMW X5 E70 (2006-2010)

Get access

BLU/BLK WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CAMERA COMPUTER DATA LINES SYSTEM DRIVER'S DOOR SWITCH BLOCK DRIVER'S SIDE OUTSIDE MIRROR ELECTRONICS JUNCTION BOX FUSE GRN WIRE GRN/YEL WIRE GRY/RED WIRE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) NAVIGATION SYSTEM NCA WIRE ORG/GRN WIRE PASSENGER'S SIDE OUTSIDE MIRROR RED WIRE RED/GRY WIRE RELAY ENERGIZED WHT WIRE YEL WIRE

Go to component: -> Power mirrors circuit, without lin bus function -> COMPUTER DATA LINES SYSTEM

Wiring diagram computer data lines system (38 of 56)

Wiring diagram computer data lines system for BMW X5 E70 (2006-2010)

Get access

BLU WIRE BRN WIRE CCC/M-ASK COMPUTER DATA LINES SYSTEM DVD CHANGER FUSE JUNCTION BOX (UNDER RIGHT SIDE OF DASH) GRN WIRE NCA WIRE NOT USED PASSIVE VIDEO SWITCH RED/GRN WIRE RELAY ENERGIZED REVERSING CAMERA VIDEO MODULE WHT WIRE YEL/BLK WIRE

Go to component: -> Rear camera circuit -> COMPUTER DATA LINES SYSTEM

Wiring diagram computer data lines system (39 of 56)

Wiring diagram computer data lines system for BMW X5 E70 (2006-2010)

Get access

BLK WIRE BLK/BRN WIRE BLU WIRE BLU/YEL WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM FUSE GRN WIRE GRN/VIO WIRE HOT AT ALL TIMES HOT IN RUN OR START LEFT REAR SEAT BACKREST HEATING LEFT REAR SEAT CUSHION HEATING LEFT REAR SEAT HEATING MODULE ORG/GRN WIRE REAR COMPARTMENT AIR CONDITIONING CONTROL MODULE REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) RED/BLU WIRE RED/YEL WIRE RELAY ENERGIZED RIGHT REAR SEAT BACKREST HEATING RIGHT REAR SEAT CUSHION HEATING RIGHT REAR SEAT HEATING MODULE WHT/BLU WIRE WHT/GRY WIRE YEL WIRE

Go to component: -> Rear heated seats circuit, with fka -> COMPUTER DATA LINES SYSTEM

Wiring diagram computer data lines system (40 of 56)

Wiring diagram computer data lines system for BMW X5 E70 (2006-2010)

Get access

BLK WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER'S SEAT BACKREST FAN 1 DRIVER'S SEAT BACKREST FAN 2 DRIVER'S SEAT BACKREST FAN 3 DRIVER'S SEAT BACKREST FAN 4 DRIVER'S SEAT CUSHION FAN 1 DRIVER'S SEAT CUSHION FAN 2 DRIVER'S SEAT CUSHION FAN 3 DRIVER'S SEAT CUSHION FAN 4 DRIVER'S SEAT CUSHION FAN 5 DRIVER'S SEAT MODULE GRN WIRE ORG/GRN WIRE RED/BRN WIRE RELAY ENERGIZED REAR POWER DISTRIBUTION BOX (RIGHT SIDE OF REAR COMPT) FUSE WHT/BLK WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE

Go to component: -> Seat ventilation circuit (1 of 2) -> COMPUTER DATA LINES SYSTEM
