Power door locks circuit for BMW X5 E53 facelift (2003-2007)

Power door locks circuit (1 of 3)

X5 BMW E53 facelift (2003-2007): Power door locks circuit (1 of 3)

Get access

ANTENNA AMPLIFIER BLK WIRE BLU WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE CENTRAL LOCKING DRIVE, DRIVER'S DOOR CENTRAL LOCKING DRIVE, FRONT PASSENGER'S DOOR DRIVER'S DOOR MODULE FUSE 20 FUSE 24 FUSE 86 FUSE HOLDER GENERAL MODULE HOT AT ALL TIMES PASSENGER'S DOOR MODULE RED/BLK WIRE RED/VIO WIRE RED/WHT WIRE SOUND SYSTEM WHT WIRE WHT/BLK WIRE WHT/YEL WIRE

Power door locks circuit (2 of 3)

X5 BMW E53 facelift (2003-2007): Power door locks circuit (2 of 3)

Get access

BLK WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/GRY WIRE BRN/WHT WIRE CENTRAL LOCKING DRIVE, REAR LEFT DOOR CENTRAL LOCKING DRIVE, REAR RIGHT DOOR FUEL TANK ACCESS FLAP LOCK MOTOR FUSE 60 FUSE HOLDER GENERAL MODULE GRY/RED WIRE GRY/YEL WIRE HAZARD WARNING FLASHER SWITCH 3) WITH CENTRAL LOCKING FUNCTION HOT AT ALL TIMES LIGHT MODULE RED/WHT WIRE TRUNK LID LOCKING SWITCH 1) UNLOCK 2) LOCK UNDERHOOD LIGHT SWITCH 1) HOOD CLOSED 2) HOOD OPEN VIO/GRN WIRE WHT WIRE YEL/RED WIRE

Power door locks circuit (3 of 3)

X5 BMW E53 facelift (2003-2007): Power door locks circuit (3 of 3)

Get access

ANTI- THEFT HORN BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/BLK WIRE BRN/YEL WIRE FUSE 13 FUSE 82 FUSE 84 FUSE HOLDER GENERAL MODULE GRY/WHT WIRE HOT AT ALL TIMES INTERIOR LIGHTS INTERIOR PROTECTION CONTROL MODULE MOTOR, BOTTOM TAILGATE REAR LID MOTOR RELAY RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE RED/WHT WIRE RED/YEL WIRE RELAY, BOTTOM TAILGATE MOTOR SWITCH, BOTTOM TAILGATE TILT SENSOR TRUNK LID SERVO MOTOR YEL/BLK WIRE YEL/BRN WIRE YEL/WHT WIRE ZV DRIVE, TOP TAILGATE
