Courtesy lamps circuit for BMW X5 E53 facelift (2003-2007)

Courtesy lamps circuit (1 of 2)

X5 BMW E53 facelift (2003-2007): Courtesy lamps circuit (1 of 2)

Get access

BRN WIRE BRN/BLK WIRE BRN/GRY WIRE BRN/WHT WIRE DRIVER'S DOOR ACCESS LIGHT DRIVER'S SIDE FOOTWELL LIGHT FRONT INTERIOR/READING LAMP FUSE FUSE HOLDER GENERAL MODULE GLOVE BOX LIGHT GRY/RED WIRE HOT AT ALL TIMES HOT IN RUN, ACCY OR START INTERIOR LIGHTS SYSTEM (ILLUMINATION CIRCUIT) LEFT REAR ACCESS LIGHT LEFT REAR DOOR CENTRAL LOCKING SWITCH LEFT REAR FOOTWELL LIGHT LEFT REAR INTERIOR LIGHT (W/ SUNROOF) PASSENGER'S DOOR ACCESS LIGHT PASSENGER'S SIDE FOOTWELL LIGHT REAR INTERIOR/ READING LAMP (W/O SUNROOF) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RIGHT REAR ACCESS LIGHT RIGHT REAR DOOR CENTRAL LOCKING SWITCH RIGHT REAR FOOTWELL LIGHT RIGHT REAR INTERIOR LIGHT (W/ SUNROOF) TRANSMISSION RANGE INDICATOR LIGHT VIO/WHT WIRE W/O SUNROOF W/ SUNROOF WHT/BRN WIRE YEL WIRE

Courtesy lamps circuit (2 of 2)

X5 BMW E53 facelift (2003-2007): Courtesy lamps circuit (2 of 2)

Get access

AIR SUSPENSION CONTROL UNIT BRN WIRE BRN/WHT WIRE CHIME MODULE CLOSED -CIRCUIT CURRENT CUT-OFF RELAY DRIVER'S DOOR CENTRAL LOCKING SWITCH DRIVER'S MAKE-UP MIRROR LIGHT DRIVER'S MAKE-UP MIRROR SWITCH FUSE FUSE HOLDER GRY/BLK WIRE GRY/RED WIRE HEATING, A/C CONTROL MODULE HOT AT ALL TIMES HOT IN RUN, ACCY OR START INTERIOR LIGHTS SYSTEM (ILLUMINATION CIRCUIT) LEFT BOOT LID LAMP LEFT FRONT DOOR OPENER LIGHTING LEFT OUTSIDE MIRROR FRONT ZONE LIGHTING LEFT REAR DOOR OPENER LIGHTING LIGHT MODULE PASSENGER'S DOOR CENTRAL LOCKING SWITCH PASSENGER'S DOOR MODULE PASSENGER'S MAKE-UP MIRROR LIGHT PASSENGER'S MAKE-UP MIRROR SWITCH PNK WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RIGHT BOOT LID LAMP RIGHT FRONT DOOR OPENER LIGHTING RIGHT OUTSIDE MIRROR FRONT ZONE LIGHTING RIGHT REAR DOOR OPENER LIGHTING VIO/GRY WIRE W/ FRONT, REAR SUSPENSION W/ FRONT SUSPENSION
