BMW X5 E53 facelift (2003-2007) (right kick panel) light module Wiring diagrams
This page contains all the electrical diagrams for the component. (right kick panel) light module, in which he is found in the car BMW X5 E53 facelift (2003-2007). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
(right kick panel) light module wiring diagram (1 of 3)
AGS TRANSMISSION CONTROL MODULE (RIGHT REAR ENGINE COMPT)
B+ DISTRIBUTION
BLK/VIO WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/ORG WIRE
BRN/VIO WIRE
ELECTRONIC IMMOBILIZER CONTROL UNIT (EWS) (LEFT KICK PANEL)
FRONT FUSE HOLDER
FUSE
FUSE CARRIER (ENGINE ELECTRONICS) (RIGHT REAR ENGINE COMPT)
GENERAL MODULE (BEHIND GLOVE BOX)
GRN/WHT WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
NCA WIRE
ORG/ WIRE
RED WIRE
RED/WHT WIRE
RED/YEL WIRE
SELECTOR LEVER POSITION SWITCH (UNDER SELECTOR LEVER COVER)
STEPTRONIC SWITCH
TRANSMISSION RANGE INDICATOR LIGHT
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> 3.0l, a/t circuit (1 of 2) -> (RIGHT KICK PANEL) LIGHT MODULE
(right kick panel) light module wiring diagram (2 of 3)
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONIC IMMOBILIZER CONTROL UNIT (EWS) (LEFT KICK PANEL)
FRONT FUSE HOLDER
FUSE
GENERAL MODULE (BEHIND GLOVE BOX)
GRN WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INTEGRATED SUPPLY MODULE (IVM)
NCA WIRE
ORG/ WIRE
PARK/ NEUTRAL POSITION SWITCH (CENTER CONSOLE)
RED WIRE
RED/YEL WIRE
SELECTOR LEVER POSITION SWITCH (UNDER SELECTOR LEVER COVER)
STEPTRONIC SWITCH
TRANSMISSION CONTROL UNIT
TRANSMISSION RANGE INDICATOR LIGHT
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> 4.4l, a/t circuit -> (RIGHT KICK PANEL) LIGHT MODULE
(right kick panel) light module wiring diagram (3 of 3)
BLK WIRE
BLK/VIO WIRE
BLU WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONIC IMMOBILIZER CONTROL UNIT (EWS) (LEFT KICK PANEL)
FRONT FUSE HOLDER
FUSE
GENERAL MODULE (BEHIND GLOVE BOX)
GRN WIRE
GRY WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INTEGRATED SUPPLY MODULE (IVM)
NCA WIRE
ORG/ WIRE
PARK/ NEUTRAL POSITION SWITCH (CENTER CONSOLE)
RED WIRE
RED/YEL WIRE
SELECTOR LEVER POSITION SWITCH (UNDER SELECTOR LEVER COVER)
STEPTRONIC SWITCH
TRANSMISSION CONTROL UNIT
TRANSMISSION RANGE INDICATOR LIGHT
VIO WIRE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
Go to component -> 4.8l, a/t circuit -> (RIGHT KICK PANEL) LIGHT MODULE
