BMW X5 E53 facelift (2003-2007) right front left front hi-range speaker speaker Wiring diagram
This page shows the only wiring diagram for the component.right front left front hi-range speaker speaker, which is found in the car BMW X5 E53 facelift (2003-2007). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right front left front hi-range speaker speaker (1 of 1)
AMPLIFIER
BLK WIRE
BLK/BRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/ORG WIRE
COMPUTER DATA LINES SYSTEM
FUSE
FUSE HOLDER FUSE
GRY/BLK WIRE
GRY/BRN WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT IN RUN, ACCY OR
LEFT REAR WOOFER SPEAKER
NCA WIRE
RADIO
RED/BLK WIRE
RED/GRN WIRE
RED/WHT WIRE
RIGHT FRONT LEFT FRONT HI-RANGE SPEAKER SPEAKER
RIGHT MID-RANGE/ HI-RANGE SPEAKER
TELEPHONE CONNECTIONS
TERMINAL R UNLOADER RELAY
VIO/BRN WIRE
VIO/WHT WIRE
W/ ON-BOARD MONITOR W/O ON-BOARD MONITOR
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRN WIRE
WHT/GRY/YEL WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Premium radio circuit, with hifi radio (1 of 3) -> RIGHT FRONT LEFT FRONT HI-RANGE SPEAKER SPEAKER
